74257 IC Quad 2 Input Multiplexer with 3 State Output 2 to 1 Multiplexer
Product details
- Product type: 2 input multiplexer or data selector with 3 state output
- IC number: 74257
- Technology: CMOS
- Number of multiplexer: 4
- Number of pins: 16
- Package: PDIP-16
- Family or category: 74 series IC
- Lead type: through hole
- Package contains: 1 x 74257 IC
₹33.00 (ex. GST)
74257 is a member of 74 series IC. this IC is a 2 input multiplexer IC with 3 state output and has 4 same circuits in one IC package. The multiplexer multiplexes data signal from a 4-bit data source to the 4-bit data line in a bus organized structure or system. The IC package has 16 lead plastic DIP-packages.
Specifications
- Voltage supply: 2V to 6V
- Current rating: 1uA
- Propagation delay: 9ns
- Speed: 10ns
- High noise immunity
- Low power dissipation
