7432 IC – Quad 2 – Input OR Gate
Product Specification
- Gate Type: OR Gate
- Number of Gates count in one IC: 6 Gates
- Inputs Number per Gate: 1
- IC Type: DIP
- Number of pins: 14
- Power Consumption: Low
- Package Contains: Unused and checked 1 piece of 7432
₹17.00 (ex. GST)
7432 IC is a member of 74xxx series gate ICs and has the functionality of OR gate or function. It will give high if either all or any of the input is high. 7432 has 4 OR gates of 2 inputs in 1 package. The internal gates in the ICs are made of Schottky Transistor of low power. OR gate finds a Maximum of 2 binary digits.
Boolean Expression
Y = A + B
Truth Table
| INPUT | OUTPUT | |
| A | B | A OR B |
| 0 | 0 | 0 |
| 0 | 1 | 1 |
| 1 | 0 | 1 |
| 1 | 1 | 1 |
Specification
- Large operating voltage
- Its operating conditions are wide
- Maximum Current that output can draw: 8mA
- It has TTL outputs
- Its power consumption is low
- Range of operating voltage: 4.75V to 5.5V
- Maximum limit of voltage: 7V
