74xx Series ICs
74HC11 7411 IC Triple 3 Input AND Gate IC
Product details
- Product type: 3 input AND Gate
- IC Number: 7411
- Number of gate or circuit: 3
- Number of inputs: 3
- Pin counts: 14
- Pin type: through hole
- Package: PDIP-14
- Package contains: 1 x 7411 IC (Original)
₹20.00 (ex. GST)
Specification
- Voltage supply: 4.75V-5.25V
- Typical voltage supply: 5V
- Low-level input voltage: 0.8V
- High-level input voltage: 2V
- Low-level output current: 16mA
- High-level output current: -0.4mA
- TTL compatible
Based on 0 reviews
Be the first to review “74HC11 7411 IC Triple 3 Input AND Gate IC”
