8×8 Dot LED Matrix Display LED Display Module

Product Specifications

  • Product type: 8×8 LED matrix
  • Chip or IC: MAX7219
  • Voltage supply: 3.7-5.3V
  • Current supply: 320mA
  • Dimensions
    • Display: 32mmX32mmx6
    • PCB: 50mx32mm
  • LED size: 5mm
  • Package contains: 1 piece of 8×8 LED matrix and 1 piece of connecting wire

185.00 (ex. GST)

8×8 LED matrix is a two-dimensional array of LEDs.8×8 Matrix has 64 LEDs and it’s 64 pixels or bits display, one LED for each display. By using the LED matrix, any symbol, character, a number of images can be displayed.  It is compatible with almost all controllers and processors like Arduino, AVR, PIC, ARM, etc.

  • Easy mounting on PCB or breadboards.
  • Small operational current
  • Light output
  • High Contrast
  • Compatible with ASCII and EBCDIC codes
  • Compatible with almost all controller and processor
  • Compact size
