Micro USB Type A Female Port Connector – SMD

Features

• Raised design provides easy insertion and withdrawal and guarantees even high reliability.
• The design of three certain restraints provides a robustious structure.
• Gold plated contacts to ensure low contact resistance.
• All materials are UL 94V-0 grade fire retardant.

Specification

• Voltage rating: – 30 VAC(RMS)
• Current rating: – 1 Amp
• Contact resistance: – 30 m Max.
• Insulation resistance: – 1000 M Min.
• Temperature storage: – -40°C to +60°C
• Durability: – 1500 cycles
• Mating force: – 35N Max.
• Unmuting force: – 2.9N Min.
• Dielectric strength: – 750 VAC Min.
