5Pc 1N4007 1amp General Purpose Rectifier Diode

1N4007 is a member of the 1N400x series, which is a family of popular 1 A general-purpose silicon rectifier diodes. The blocking voltage of the series varies according to diode number, 1N4007 denotes 1000 volts. It is commonly used in AC Adapters, which is used in common household appliances.

A general-purpose diode is a two-terminal semiconductor device. It allows current to pass only in one direction, from its anode to cathode.

Features

• Diffused junction
• High current capability and low forward voltage drop
• Surge overload rating to 30A peak
• Low reverse leakage current

Mechanical Data

• Case: DO-41
• Case Material: Molded plastic. UL flammability classification rating 94V-0
• Moisture sensitivity: level 1 per J-STD-020D
• Terminal finish: bright tin. Plated leads solderable per MIL-STD-202, method 208
• Polarity: cathode band
• Marking: type number
• Weight: approximately 0.30g

Specification

• Peak repetitive reverse voltage: 1000V
• Working peak reverse voltage: 1000V
• DC blocking voltage: 1000V
• RMS reverse voltage: 700V
• Forward voltage: 1V
• Average rectified output current: 1A
• Non-repetitive peak forward surge current: 30A
• Peak reverse current: 5µA @25℃
• Power dissipation: 3W

Application

• DC-DC converters
• AC-DC Converters
• DC-AC converters
• Voltage switching
• Clamping circuit
• Power supply
• Voltage regulators
• As signal modulators and demodulators
• Voltage stabilizer
